07 Strips & Profiles > The 9,6W/m Outdoor 24V
7829AW/W
IP68 SMD LED light strip, 70LEDs/meter, 9,6W/meter.
Supplied in 5 meters roll with 3M double face adhesive tape.
Can be cut every 10cm.
Avoid direct sunlight.
Requires 24V DC constant voltage LED driver.
Complies with standard EN60598-1 and any other specific standards.
Supplied in 5 meters roll with 3M double face adhesive tape.
Can be cut every 10cm.
Avoid direct sunlight.
Requires 24V DC constant voltage LED driver.
Complies with standard EN60598-1 and any other specific standards.
Dimensions
Downloads
Physical Specification
Item Group
07 Strips & Profiles
Family
The 9,6W/m Outdoor 24V
Order Code
7829AW/W
Material
Silicone
Shape
Rectangular
Length
5000mm
Width
10mm
Surface Ceiling
Yes
Surface Wall
Yes
Surface Floor/Ground
Yes
Indoor
Yes
Outdoor
Yes
Electrical Characteristics
Gear
Order Separately
Fitting
Input Type
Constant Voltage
Input Voltage
24V DC
Safety Class
Power (Watts)
9,6W/m
IP Rating
IP68
Light Source
LED built in
LED Type
SMD 2835
LED Number
70Leds/m
Illumination Data
Colour Temperature
3000K
Lumen Output
900lm/m
Light Efficiency
93,75lm/W
CRI
90
Illumination Diagram
Packing Info
Pcs/Carton
40
Barcode
5291889089360
HS Code
9405423100
Energy Label
Energy Class
Certification & Warranty
Warranty
3 years
Wee Directive
Yes
Year in which the CE mark was affixed
26
