07 Strips & Profiles > The COB Strips 10mm
7846H/W
High Efficiency COB LED light strip, 480LEDs/meter, 14.5W/meter.
Supplied in 5 meters roll with 3M double face adhesive tape.
Can be cut every 5cm.
Requires 24V DC constant voltage LED driver.
Complies with standard EN60598-1 and any other specific standards.
Supplied in 5 meters roll with 3M double face adhesive tape.
Can be cut every 5cm.
Requires 24V DC constant voltage LED driver.
Complies with standard EN60598-1 and any other specific standards.
Dimensions
Downloads
Physical Specification
Item Group
07 Strips & Profiles
Family
The COB Strips 10mm
Order Code
7846H/W
Shape
Rectangular
Length
5000mm
Width
10mm
Surface Ceiling
Yes
Surface Wall
Yes
Surface Floor/Ground
Yes
Indoor
Yes
Electrical Characteristics
Gear
Order Separately
Fitting
Input Type
Constant Voltage
Input Voltage
24V DC
Safety Class
Power (Watts)
14,5W
IP Rating
IP20
Light Source
LED built in
LED Type
COB
F Mark
Illumination Data
Colour Temperature
3000K
Lumen Output
2175lm/m
Light Efficiency
150lm/W
CRI
90
Illumination Diagram
Packing Info
Box Weight
0.240kg
Pcs/Carton
50
Barcode
5291889088264
HS Code
9405499090
Energy Label
Energy Class
Certification & Warranty
Warranty
5 years
Wee Directive
Yes
Year in which the CE mark was affixed
25
