08 Strips & Profiles > The Ultra Slim Range 24V
7833/C
Slim Flexible LED light strip, with SMD2110 LEDs, 196LEDs/meter, 14,4W/meter.Supplied in 5 meters roll with white PCB and double adhesive tape for a better fixing.
Can be cut every 3,5cm (7-LED segment).
Requires 24V DC constant voltage LED driver.
Complies with standard EN60598-1 and any other specific standards.
Can be cut every 3,5cm (7-LED segment).
Requires 24V DC constant voltage LED driver.
Complies with standard EN60598-1 and any other specific standards.
Dimensions
Downloads
Physical Specification
Item Group
08 Strips & Profiles
Family
The Ultra Slim Range 24V
Order Code
7833/C
Shape
Rectangular
Length
5m
Width
4mm
Surface Ceiling
Yes
Surface Wall
Yes
Surface Floor/Ground
Yes
Indoor
Yes
Electrical Characteristics
Gear
Order Separately
Fitting
Input Type
Constant Voltage
Input Voltage
24V DC
Safety Class
Power (Watts)
14,4W/m
IP Rating
IP20
Light Source
LED built in
LED Type
SMD 2110
LED Brand
Refond
LED Number
196Leds/m
Illumination Data
Colour Temperature
4000K
Lumen Output
1300lm/m
Light Efficiency
90,28lm/W
CRI
90
Illumination Diagram
Packing Info
Box Length
24cm
Box Width
21,5cm
Box Height
2cm
Box Weight
0.150kg
Pcs/Carton
40
Barcode
5291889058816
HS Code
9405499090
Energy Label
Energy Class
Certification & Warranty
Warranty
5 years
Wee Directive
Yes
Year in which the CE mark was affixed
18
