21 Industrial & Floodlights > The COB LED Slim Line Die cast

7034B/G/C

50W COB LED Slim floodlight, IP65.

Supplied with non-dimmable LED driver.

Complies with standard EN60598-1 and any other specific standards.
Outdoor
Ceiling
Wall
IP
CRI
Adjustable
Beam Angle
CE
Dimensions
Downloads

Physical Specification

+
Item Group
21 Industrial & Floodlights
Family
The COB LED Slim Line Die cast
Order Code
7034B/G/C
Colour
Grey
Material
Die Cast
Shape
Rectangular
Length
250mm
Width
200mm
Height
120mm
Surface Ceiling
Yes
Surface Wall
Yes
Surface Floor/Ground
Yes
Outdoor
Yes
Adjustable
1 Direction

Electrical Characteristics

+
Gear
Built In
Fitting + Driver
Input Voltage
100-240V
50 Hz
Yes
60 Hz
Yes
Safety Class
Power (Watts)
50W
IP Rating
IP65
Light Source
LED built in
Dimmable
No
Cable Length
100cm
F Mark
Fitting
Input Type
Constant Current
Input Current
1400mA
Voltage
34V
Power (Watts)
47,6W
IP Rating
IP65
Light Source
LED built in
LED Type
COB
LED Brand
Epistar
Gear
Gear Type
Led Driver
Input Voltage
100-240V
50 Hz
Yes
60 Hz
Yes
Power (Watts)
31-50W
Power Factor
0,9
Constant Current
Yes
1400mA
22-36V
IP Rating
IP20
Safety Class
Dimmable
No
Housing Material
Plastic
Output Terminal
Connector

Illumination Data

+
Colour Temperature
4000K
Lumen Output
4050lm
Light Efficiency
81lm/W
CRI
75
Beam Angle
130°
Illumination Diagram

Packing Info

+
Box Length
20,5cm
Box Width
15,5cm
Box Height
28cm
Box Weight
2,2Kg
Pcs/Carton
10
Barcode
5291889034278
HS Code
9405409900

Energy Label

+

Certification & Warranty

+
Warranty
2 Years
Weee Directive
Yes
Year in which the CE mark was affixed
13
