13 Wall & Ceiling LED > The Backlight Range
67450/AN/W
7W LED Wall and Ceiling Dark light.
Complete with non-dimmable LED driver.
Complies with standard EN60598-1 and any other specific standards.
Complete with non-dimmable LED driver.
Complies with standard EN60598-1 and any other specific standards.
Dimensions
Downloads
Physical Specification
Item Group
13 Wall & Ceiling LED
Family
The Backlight Range
Order Code
67450/AN/W
Colour
Anthracite
Material
ABS
Diffuser Material
PC
Shape
Circular
Height
60mm
Diameter
163mm
Surface Ceiling
Yes
Surface Wall
Yes
Indoor
Yes
Outdoor
Yes
IK Rating
8
Electrical Characteristics
Gear
Built In
Fitting + Driver
Input Voltage
220-240V
50 Hz
Yes
60 Hz
Yes
Safety Class
Power (Watts)
7W
IP Rating
IP54
Light Source
LED built in
Dimmable
No
F Mark
Fitting
Input Type
Constant Current
Input Current
300mA
Voltage
20V
Power (Watts)
6W
IP Rating
IP54
Light Source
LED built in
LED Type
SMD 2835
LED Brand
Epistar
Gear
Gear Type
Led Driver
Input Voltage
220-240V
50 Hz
Yes
60 Hz
Yes
Power (Watts)
3,6-6W
Power Factor
0,5
Constant Current
Yes
300mA
12-20V
IP Rating
IP20
Safety Class
Dimmable
No
Housing Material
Plastic
Output Terminal
Cable
Illumination Data
Colour Temperature
3000K
Lumen Output
600lm
Light Efficiency
85,7lm/W
CRI
80
Illumination Diagram
Dark Light
Yes
Packing Info
Box Length
17,5cm
Box Width
17,5cm
Box Height
8cm
Box Weight
0.404kg
Pcs/Carton
24
Barcode
5291889057970
HS Code
9405114090
Energy Label
Certification & Warranty
Warranty
2 years
Wee Directive
Yes
Year in which the CE mark was affixed
18
