13 Wall & Ceiling LED > Outdoor Wall Dark Lights Die cast
67398/AN/W
3W LED wall light, IP54, ideal for both indoor and outdoor
installation.
Supplied with non-dimmable LED driver.
Complies with standard EN60598-1 and any other specific standards.
Supplied with non-dimmable LED driver.
Complies with standard EN60598-1 and any other specific standards.
Dimensions
Downloads
Physical Specification
Item Group
13 Wall & Ceiling LED
Family
Outdoor Wall Dark Lights Die cast
Order Code
67398/AN/W
Colour
Anthracite
Material
Die Cast
Shape
Rectangular
Length
90mm
Width
68mm
Height
107mm
Surface Wall
Yes
Indoor
Yes
Outdoor
Yes
Electrical Characteristics
Gear
Built In
Fitting + Driver
Input Voltage
100-240V
50 Hz
Yes
60 Hz
Yes
Safety Class
Power (Watts)
3W
IP Rating
IP54
Light Source
LED built in
Dimmable
No
F Mark
Fitting
Input Type
Constant Current
Input Current
350mA
Voltage
8V
Power (Watts)
2,9W
IP Rating
IP54
Light Source
LED built in
LED Type
COB
LED Brand
Cree
Gear
Gear Type
Led Driver
Input Voltage
100-240V
50 Hz
Yes
60 Hz
Yes
Power (Watts)
1-3,5W
Power Factor
0,5
Constant Current
Yes
350mA
3-10V
IP Rating
IP20
Safety Class
Dimmable
No
Ambient Temp
-20ºC~50ºC
Operating Temp
75ºC
Housing Material
Plastic
Output Terminal
Cable
Illumination Data
Colour Temperature
3000K
Lumen Output
200lm
Light Efficiency
66,67lm/W
CRI
80
Illumination Diagram
Dark Light
Yes
Packing Info
Box Length
10,5cm
Box Width
9cm
Box Height
12cm
Box Weight
0.491kg
Pcs/Carton
24
Barcode
5291889049593
HS Code
9405413990
Energy Label
Certification & Warranty
Warranty
2 years
Wee Directive
Yes
Year in which the CE mark was affixed
16
