05 Downlights Fixed > Floating Square Panels Range Adjustable Cut Out Hole
50120CE/C
20W Downlight LED, IP20.
Complete with 700mA driver.
Complies with standard EN60598-1 and any other specific standards.
Complete with 700mA driver.
Complies with standard EN60598-1 and any other specific standards.
Dimensions
Downloads
Physical Specification
Item Group
05 Downlights Fixed
Family
Floating Square Panels Range Adjustable Cut Out Hole
Order Code
50120CE/C
Colour
White
Material
Aluminium
Diffuser Material
PC
Shape
Rectangular
Length
200mm
Width
200mm
Height
10mm
Cutout Hole Diameter
70mm-180mm
Recessed Ceiling
Yes
Depth Required
50mm
Indoor
Yes
Adjustable
No
Electrical Characteristics
Gear
External-Included
Fitting + Driver
Input Voltage
220-240V
50 Hz
Yes
60 Hz
Yes
Safety Class
Power (Watts)
20W
IP Rating
IP20
Light Source
LED built in
Dimmable
No
F Mark
Fitting
Input Type
Constant Current
Input Current
700mA
Voltage
22,5V
Safety Class
Power (Watts)
15,75W
IP Rating
IP20
Light Source
LED built in
LED Type
SMD 4014
LED Brand
Zhaochi
Gear
Gear Type
Led Driver
Input Voltage
220-240V
50 Hz
Yes
60 Hz
Yes
Power (Watts)
12,6-21W
Power Factor
0,9
Constant Current
Yes
700mA
18-30V
IP Rating
IP20
Safety Class
Dimmable
No
Housing Material
Plastic
Output Terminal
Cable
Illumination Data
Colour Temperature
4000K
Lumen Output
2300lm
Light Efficiency
115lm/W
CRI
90
Illumination Diagram
Packing Info
Box Weight
0.492kg
Pcs/Carton
40
Barcode
5291889073970
HS Code
9405413990
Energy Label
Energy Class
Energy Consumption
20kWh/1000h
Certification & Warranty
Warranty
2 years
Wee Directive
Yes
Year in which the CE mark was affixed
22
