05 Downlights Fixed > The Dark Light Dome Reflector Aluminium
10122FD/W/C
22W LED Dark Light Dome Reflector, IP20.
Complete with 600mA driver.
Complies with standard EN60598-1 and any other specific standards.
Complete with 600mA driver.
Complies with standard EN60598-1 and any other specific standards.
Dimensions
Downloads
Physical Specification
Item Group
05 Downlights Fixed
Family
The Dark Light Dome Reflector Aluminium
Order Code
10122FD/W/C
Colour
White
Material
Die Cast
Shape
Circular
Height
60mm
Diameter
225mm
Cutout Hole Diameter
210mm
Recessed Ceiling
Yes
Depth Required
90mm
Indoor
Yes
Adjustable
No
Electrical Characteristics
Gear
External-Included
Fitting + Driver
Input Voltage
220-240V
50 Hz
Yes
60 Hz
Yes
Safety Class
Power (Watts)
22W
IP Rating
IP20
Light Source
LED built in
Dimmable
No
F Mark
Fitting
Input Type
Constant Current
Input Current
600mA
Voltage
35V
Safety Class
Power (Watts)
21W
IP Rating
IP20
Light Source
LED built in
LED Type
SMD 2835
LED Brand
Sanan
F Mark
Gear
Gear Type
Led Driver
Input Voltage
220-240V
50 Hz
Yes
60 Hz
Yes
Power (Watts)
15-21W
Power Factor
0,9
Constant Current
Yes
600mA
25-35V
IP Rating
IP20
Safety Class
Dimmable
No
Housing Material
Plastic
Output Terminal
Cable
Illumination Data
Colour Temperature
4000K
Lumen Output
1550lm
Light Efficiency
70,45lm/W
CRI
80
Illumination Diagram
Dark Light
Yes
Packing Info
Box Length
23,5cm
Box Width
23cm
Box Height
6,5cm
Box Weight
0.615kg
Pcs/Carton
20
Barcode
5291889051633
HS Code
9405413990
Energy Label
Certification & Warranty
Warranty
3 years
Average Lifetime
30000hrs
Wee Directive
Yes
Year in which the CE mark was affixed
17
